Hover to zoomNSG-8008-8-T1-UF-320
Brand: Nansin · JapanPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity326 kg
Wheel Size8"
Wheel MaterialPolyurethane (PU)
FunctionRigid
MountingTop Plate
Wheel Diameter200 mm
Tread Width45 mm
Overall Height230 mm
Top Plate Size159 X 113 mm
Bolt Hole Centre133 X 86 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The heavy-duty shock absorbing castor is designed to improve trolleys handling under heavy loads, smooth transport is possible even if the left and right side are at different heights. Recommended application : Trolleys for handling in the logistics and automotive industry.
Floor Suitability
Suitable for all types of industrial floor, even outdoors floors, they do not mark fragile floors. It easily overcome obstacles.
Origin
Nansin – Japan
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 6" | NSG-8006-1-T1-UF-280 | PU | SWIVEL | 150 | 45 | 285 | 185 ~ 205 | 159 X 113 | 133 X 86 |
| 6" | NSG-8006-8-T1-UF-280 | PU | RIGID | 150 | 45 | 285 | 185 ~ 205 | 159 X 113 | 133 X 86 |
| 8" | NSG-8008-1-T1-UF-320 | PU | SWIVEL | 200 | 45 | 326 | 230 ~ 250 | 159 X 113 | 133 X 86 |
| 8" | NSG-8008-8-T1-UF-320 | PU | RIGID | 200 | 45 | 326 | 230 ~ 250 | 159 X 113 | 133 X 86 |
