Hover to zoomHD-YC512SM520KUSB
Brand: Herdar · TaiwanPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity320 kg
Wheel Size4"
Wheel MaterialPolyurethane (PU)
FunctionSwivel
MountingTop Plate
Wheel Diameter100 mm
Tread Width50 mm
Overall Height143 mm
Top Plate Size116 X 100 mm
Bolt Hole Centre77 X 67 / 92 X 76 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The very thick yellow polyurethane designed to improve trolleys’ handling under heavy loads on uneven surface. Excellent ability to overcome obstacles, reduced fatigue when pushing the trolley. Is also resistance to most chemicals, solvents, water and acids.
Floor Suitability
Suitable for all types of industrial floor, even outdoors floors, they do not mark fragile floors. It easily overcome obstacles.
Origin
Herdar – Taiwan
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 4" | YC512SM420KU | PU | SWIVEL | 100 | 50 | 320 | 143 | 116 X 100 | 77 X 67 / 92 X 76 |
| 4" | YC512RM420KU | PU | RIGID | 100 | 50 | 320 | 143 | 116 X 100 | 77 X 67 / 92 X 76 |
| 4" | YC512SM420KUSB | PU | SIDE BRAKE | 100 | 50 | 320 | 143 | 116 X 100 | 77 X 67 / 92 X 76 |
| 4" | A420KU | PU | WHEEL | 100 | 50 | 320 | 50mm | 17mm | Ball Bearing |
| 5" | YC512SM520KU | PU | SWIVEL | 125 | 50 | 400 | 165 | 116 X 100 | 77 X 67 / 92 X 76 |
| 5" | YC512RM520KU | PU | RIGID | 125 | 50 | 400 | 165 | 116 X 100 | 77 X 67 / 92 X 76 |
| 5" | YC512SM520KUSB | PU | SIDE BRAKE | 125 | 50 | 400 | 165 | 116 X 100 | 77 X 67 / 92 X 76 |
| 5" | A520KU | PU | WHEEL | 125 | 50 | 400 | 50mm | 17mm | Ball Bearing |
| 6" | YC512SM620KU | PU | SWIVEL | 150 | 50 | 420 | 190 | 116 X 100 | 77 X 67 / 92 X 76 |
| 6" | YC512RM620KU | PU | RIGID | 150 | 50 | 420 | 190 | 116 X 100 | 77 X 67 / 92 X 76 |
| 6" | YC512SM620KUSB | PU | SIDE BRAKE | 150 | 50 | 420 | 190 | 116 X 100 | 77 X 67 / 92 X 76 |
| 6" | A620KU | PU | WHEEL | 150 | 50 | 420 | 50mm | 20mm | Ball Bearing |
| 8" | YC512SM820KU | PU | SWIVEL | 200 | 50 | 450 | 240 | 116 X 100 | 77 X 67 / 92 X 76 |
| 8" | YC512RM820KU | PU | RIGID | 200 | 50 | 450 | 240 | 116 X 100 | 77 X 67 / 92 X 76 |
| 8" | YC512SM820KUSB | PU | SIDE BRAKE | 200 | 50 | 450 | 240 | 116 X 100 | 77 X 67 / 92 X 76 |
| 8" | A820KU | PU | WHEEL | 200 | 50 | 450 | 50mm | 20mm | Ball Bearing |
Request a Quote for HD-YC512SM520KUSB
Tell us the quantity and your application. We will reply with pricing and a recommendation.
