Antistatic and Electrically-Conductive Castors & Wheels
DL-SDD24P10A-CPB
90 kg4"Conductive / AntistaticTotal Brake
Hover to zoomDL-SDD24P10A-CPR
Brand: Denly · GermanyPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity90 kg
Wheel Size4"
Wheel MaterialConductive / Antistatic
FunctionRigid
MountingTop Plate
Wheel Diameter100 mm
Tread Width32 mm
Overall Height133.5 mm
Top Plate Size96 X 63 mm
Bolt Hole Centre75 X 45.5 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The Medium Duty electrical conductive TPR rubber (Flat Tread) castor suitable for all types of trolleys and for ESD sensible environments.
Floor Suitability
Suitable for all types of floors, even outdoors.They easily overcome obstacles, do not mark and damage fragile floors.
Origin
Denly Germany – Made in China
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 3" | DL-SDD23P10A-CPS | CONDUCTIVE TPR | SWIVEL | 75 | 32 | 60 | 105 | 96 X 63 | 75 X 45.5 |
| 3" | DL-SDD23P10A-CPR | CONDUCTIVE TPR | RIGID | 75 | 32 | 60 | 105 | 96 X 63 | 75 X 45.5 |
| 3" | DL-SDD23P10A-CPB | CONDUCTIVE TPR | TOTAL BRAKE | 75 | 32 | 60 | 105 | 96 X 63 | 75 X 45.5 |
| 3" | DL-SDD23P10A | CONDUCTIVE TPR | WHEEL | 75 | 32 | 60 | 41mm | 10mm | Ball Bearing |
| 4" | DL-SDD24P10A-CPS | CONDUCTIVE TPR | SWIVEL | 100 | 32 | 90 | 133.5 | 96 X 63 | 75 X 45.5 |
| 4" | DL-SDD24P10A-CPR | CONDUCTIVE TPR | RIGID | 100 | 32 | 90 | 133.5 | 96 X 63 | 75 X 45.5 |
| 4" | DL-SDD24P10A-CPB | CONDUCTIVE TPR | TOTAL BRAKE | 100 | 32 | 90 | 133.5 | 96 X 63 | 75 X 45.5 |
| 4" | DL-SDD24P10A | CONDUCTIVE TPR | WHEEL | 100 | 32 | 90 | 41mm | 10mm | Ball Bearing |
| 5" | DL-SDD25P10A-CPS | CONDUCTIVE TPR | SWIVEL | 125 | 32 | 110 | 158 | 96 X 63 | 75 X 45.5 |
| 5" | DL-SDD25P10A-CPR | CONDUCTIVE TPR | RIGID | 125 | 32 | 110 | 158 | 96 X 63 | 75 X 45.5 |
| 5" | DL-SDD25P10A-CPB | CONDUCTIVE TPR | TOTAL BRAKE | 125 | 32 | 110 | 158 | 96 X 63 | 75 X 45.5 |
| 5" | DL-SDD25P10A | CONDUCTIVE TPR | WHEEL | 125 | 32 | 110 | 41mm | 10mm | Ball Bearing |
Request a Quote for DL-SDD24P10A-CPR
Tell us the quantity and your application. We will reply with pricing and a recommendation.
