Hover to zoomNSG-STM100VSE
Brand: Nansin · JapanPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity80 kg
Wheel Size3"
Wheel MaterialRubber
FunctionSwivel
MountingTop Plate
Wheel Diameter75 mm
Tread Width32 mm
Overall Height100 mm
Top Plate Size81 X 81 mm
Bolt Hole Centre63 X 63 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The Nansin electrical conductive rubber castor suitable for medium-heavy duty trolleys and for ESD sensible environments.
Floor Suitability
Suitable for all types of floors, even outdoors. They easily overcome obstacles, do not damage and do not mark fragile floors.
Origin
Nansin – Japan
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 3" | STM075VAE(OR) | ORANGE RUBBER | SWIVEL | 75 | 32 | 80 | 100 | 81 X 81 | 63 X 63 |
| 3" | SKM075VAE(OR) | ORANGE RUBBER | RIGID | 75 | 32 | 80 | 100 | 95 X 71 | 63 X 40 |
| 3" | STM075VAE(OR)-S2 | ORANGE RUBBER | SIDE BRAKE | 75 | 32 | 80 | 100 | 81 X 81 | 63 X 63 |
| 3" | STM075VAE(OR)W3R | ORANGE RUBBER | TOTAL BRAKE | 75 | 32 | 80 | 100 | 81 X 81 | 63 X 63 |
| 3" | VAE075(OR) | ORANGE RUBBER | WHEEL | 75 | 32 | 80 | 35mm | 10mm | Commercial Bearing |
| 4" | STM100VSE(OR) | ORANGE RUBBER | SWIVEL | 100 | 32 | 100 | 144 | 95 X 95 | 73 X 73 / 70 X 70 |
| 4" | SKM100VSE(OR) | ORANGE RUBBER | RIGID | 100 | 32 | 100 | 144 | 115 X 80 | 80 X 45 |
| 4" | STM100VSE(OR)-S2 | ORANGE RUBBER | SIDE BRAKE | 100 | 32 | 100 | 144 | 95 X 95 | 73 X 73 / 70 X 70 |
| 4" | STM100VSE(OR)-W3R | ORANGE RUBBER | TOTAL BRAKE | 100 | 32 | 100 | 144 | 95 X 95 | 73 X 73 / 70 X 70 |
| 4" | VSE100(OR) | ORANGE RUBBER | WHEEL | 100 | 32 | 100 | 42mm | 12mm | Commercial Bearing |
| 5" | STM130VSE(OR) | ORANGE RUBBER | SWIVEL | 130 | 38 | 180 | 177 | 105 X 105 | 82 X 82 / 80 X 80 |
| 5" | SKM130VSE(OR) | ORANGE RUBBER | RIGID | 130 | 38 | 180 | 177 | 138 X 90 | 100 X 56 |
| 5" | STM130VSE(OR)-S2 | ORANGE RUBBER | SIDE BRAKE | 130 | 38 | 180 | 177 | 105 X 105 | 82 X 82 / 79 X 79 |
| 5" | STM130VSE(OR)-W3R | ORANGE RUBBER | TOTAL BRAKE | 130 | 38 | 180 | 177 | 105 X 105 | 82 X 82 / 79 X 79 |
| 5" | VSE130(OR) | ORANGE RUBBER | WHEEL | 130 | 38 | 180 | 52mm | 20mm | Commercial Bearing |
| 6" | STM150VSE(OR) | ORANGE RUBBER | SWIVEL | 150 | 42 | 200 | 198 | 120 X 120 | 93 X 93 / 90 X 90 |
| 6" | SKM150VSE(OR) | ORANGE RUBBER | RIGID | 150 | 42 | 200 | 198 | 138 X 90 | 100 X 56 |
| 6" | STM150VSE(OR)-S2 | ORANGE RUBBER | SIDE BRAKE | 150 | 42 | 200 | 198 | 120 X 120 | 93 X 93 / 87 X 87 |
| 6" | STM150VSE(OR)-W3R | ORANGE RUBBER | TOTAL BRAKE | 150 | 42 | 200 | 198 | 120 X 120 | 93 X 93 / 87 X 87 |
| 6" | VSE150(OR) | ORANGE RUBBER | WHEEL | 150 | 42 | 200 | 55mm | 20mm | Commercial Bearing |
| 8" | STM200VSE(OR) | ORANGE RUBBER | SWIVEL | 200 | 45 | 250 | 250 | 140 X 140 | 115 X 115 / 105 X 105 |
| 8" | SKM200VSE(OR) | ORANGE RUBBER | RIGID | 200 | 45 | 250 | 250 | 152 X 100 | 112 X 63 |
| 8" | STM200VSE(OR)-S2 | ORANGE RUBBER | SIDE BRAKE | 200 | 45 | 250 | 250 | 140 X 140 | 115 X 115 / 105 X 105 |
| 8" | STM200VSE(OR)-W3R | ORANGE RUBBER | TOTAL BRAKE | 200 | 45 | 250 | 250 | 140 X 140 | 115 X 115 / 105 X 105 |
| 8" | VSE200(OR) | ORANGE RUBBER | WHEEL | 200 | 45 | 250 | 55mm | 20mm | Commercial Bearing |
