Hover to zoomNSG-TES100NRC
Brand: Nansin · JapanPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity60 kg
Wheel Size4"
Wheel MaterialGrey Rubber (Non-Marking)
FunctionSwivel
MountingTop Plate
Wheel Diameter100 mm
Tread Width27 mm
Overall Height122 mm
Top Plate Size100 X 58 mm
Bolt Hole Centre82 X 40 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
Suitable for trolleys and machinery with light and medium-duty loads, also good resistance to wear and tearing. Suitable for indoor & outdoor use.
Floor Suitability
Suitable for all types of industrial floor, even outdoors floors, they do not mark fragile floors.
Origin
Nansin – Japan
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 4" | NSG-TES100NRC | ELASTIC GREY RUBBER | SWIVEL | 100 | 27 | 60 | 122 | 100 X 58 | 82 X 40 |
| 4" | NSG-KES100NRC | ELASTIC GREY RUBBER | RIGID | 100 | 27 | 60 | 122 | 100 X 58 | 82 X 40 |
