Hover to zoomKRS-LM-511-S-TPR
Brand: Kerisa · Malaysia / ChinaPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity90 kg
Wheel Size5"
Wheel MaterialGrey Rubber (Non-Marking)
FunctionSwivel
MountingTop Plate
Wheel Diameter125 mm
Tread Width32 mm
Overall Height154 mm
Top Plate Size95 X 63 mm
Bolt Hole Centre73 X 45 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
Suitable for trolleys and machinery with light and medium-duty loads, also good resistance to wear and tearing. Suitable for indoor & outdoor use.
Floor Suitability
Suitable for all types of industrial floor, even outdoors floors, they do not mark fragile floors.
Origin
Kerisa – Made in China
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 3" | KRS-LM-311-S-TPR | GREY RUBBER | SWIVEL | 75 | 32 | 70 | 107 | 95 X 63 | 73 X 45 |
| 3" | KRS-LM-311-R-TPR | GREY RUBBER | RIGID | 75 | 32 | 70 | 107 | 95 X 63 | 73 X 45 |
| 3" | KRS-LM-311-S-DB-TPR | GREY RUBBER | TOTAL BRAKE | 75 | 32 | 70 | 107 | 95 X 63 | 73 X 45 |
| 3" | KRS-TRG-311-06-BB | GREY RUBBER | WHEEL | 75 | 32 | 70 | 41mm | 10mm | Ball Bearing |
| 4" | KRS-LM-411-S-TPR | GREY RUBBER | SWIVEL | 100 | 32 | 80 | 130 | 95 X 63 | 73 X 45 |
| 4" | KRS-LM-411-R-TPR | GREY RUBBER | RIGID | 100 | 32 | 80 | 130 | 95 X 63 | 73 X 45 |
| 4" | KRS-LM-411-S-DB-TPR | GREY RUBBER | TOTAL BRAKE | 100 | 32 | 80 | 130 | 95 X 63 | 73 X 45 |
| 4" | KRS-TRG-411-06-BB | GREY RUBBER | WHEEL | 100 | 32 | 80 | 41mm | 10mm | Ball Bearing |
| 5" | KRS-LM-511-S-TPR | GREY RUBBER | SWIVEL | 125 | 32 | 90 | 154 | 95 X 63 | 73 X 45 |
| 5" | KRS-LM-511-R-TPR | GREY RUBBER | RIGID | 125 | 32 | 90 | 154 | 95 X 63 | 73 X 45 |
| 5" | KRS-LM-511-S-DB-TPR | GREY RUBBER | TOTAL BRAKE | 125 | 32 | 90 | 154 | 95 X 63 | 73 X 45 |
| 5" | KRS-TRG-511-06-BB | GREY RUBBER | WHEEL | 125 | 32 | 90 | 41mm | 10mm | Ball Bearing |
