Hover to zoomHD-C512RM620EKU
Brand: Herdar · TaiwanPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity400 kg
Wheel Size6"
Wheel MaterialPolyurethane (PU)
FunctionRigid
MountingTop Plate
Wheel Diameter150 mm
Tread Width50 mm
Overall Height190 mm
Top Plate Size116 X 100 mm
Bolt Hole Centre84 X 71 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
High rebound elastic polyurethane designed to improve trolleys’ handling under heavy loads on uneven surface. This wheel is quiet and very comfort operation becouse of thick and elastic tread. It helps prolong equipment life and protect floor.
Floor Suitability
Suitable for all types of industrial floor, even outdoors floors, they do not mark fragile floors. It easily overcome obstacles.
Origin
Herdar – Taiwan
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 6" | HD-C512SM620EKU | PU | SWIVEL | 150 | 50 | 400 | 190 | 116 X 100 | 84 X 71 |
| 6" | HD-C512RM620EKU | PU | RIGID | 150 | 50 | 400 | 190 | 116 X 100 | 84 X 71 |
| 6" | HD-C512SM620EKUSB | PU | SIDE BRAKE | 150 | 50 | 400 | 190 | 116 X 100 | 84 X 71 |
| 6" | HD-2WEKU/1550B49B | PU | WHEEL | 150 | 50 | 400 | 52mm | 20mm | Ball Bearing |
