Hover to zoomGB-4404481
Brand: Globe · ChinaPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity420 kg
Wheel Size6"
Wheel MaterialCast Iron
FunctionSwivel
MountingTop Plate
Wheel Diameter150 mm
Tread Width50 mm
Overall Height193 mm
Top Plate Size114 X 100 mm
Bolt Hole Centre84 X 71 mm
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The heavy duty cast iron “V" groove wheels are designed for use on inverted angle track. The flat surface of the tread allows rooling on the floor when “off track". Excellent for hight temperature applications and is resistance to abrasion.
Floor Suitability
They may damage fragile flooring.
Origin
Globe – Made in China
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Size of Plate (mm) | Hole Centre (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 4" | GB-4404556 | CAST IRON | SWIVEL | 100 | 50 | 290 | 145 | 114 X 100 | 84 X 71 |
| 4" | GB-4404557 | CAST IRON | RIGID | 100 | 50 | 290 | 145 | 114 X 100 | 84 X 71 |
| 4" | GB-4404558 | CAST IRON | WHEEL | 100 | 50 | 290 | 62mm | 12mm | Roller Bearing |
| 5" | GB-4404559 | CAST IRON | SWIVEL | 125 | 50 | 360 | 168 | 114 X 100 | 84 X 71 |
| 5" | GB-4404560 | CAST IRON | RIGID | 125 | 50 | 360 | 168 | 114 X 100 | 84 X 71 |
| 5" | GB-4404561 | CAST IRON | WHEEL | 125 | 50 | 360 | 62mm | 12mm | Roller Bearing |
| 6" | GB-4404481 | CAST IRON | SWIVEL | 150 | 50 | 420 | 193 | 114 X 100 | 84 X 71 |
| 6" | GB-4404482 | CAST IRON | RIGID | 150 | 50 | 420 | 193 | 114 X 100 | 84 X 71 |
| 6" | GB-4404483 | CAST IRON | WHEEL | 150 | 50 | 420 | 62mm | 12mm | Roller Bearing |
| 8" | GB-4404562 | CAST IRON | SWIVEL | 200 | 50 | 430 | 243 | 114 X 100 | 84 X 71 |
| 8" | GB-4404563 | CAST IRON | RIGID | 200 | 50 | 430 | 243 | 114 X 100 | 84 X 71 |
| 8" | GB-4404564 | CAST IRON | WHEEL | 200 | 50 | 430 | 62mm | 12mm | Roller Bearing |
