Hover to zoomGB-3303509A
Brand: Globe · ChinaPrice on requestPricing depends on quantity and configuration. Get a quote in one message.
Load Capacity130 kg
Wheel Size4"
Wheel MaterialPolyurethane (PU)
FunctionSide Brake
MountingThreaded Stem
Wheel Diameter100 mm
Tread Width32 mm
Overall Height132 mm
Stem SizeM12 X 35 / M12 X 25 mm
BearingBall Bearing
Brand-new quality parts
Free selection advice
Consultation worldwide
Applications
The round profile reduces the start-up coefficient when the castor are positioned at 90° from the line of movement. Excellent rolling resistance and elasticity and good resistance to wear and tear.
Floor Suitability
Suitable for all types of industrial floor, even outdoors.They do not mark fragile floors. It easily overcome obstacles.
Origin
Globe – Made in China
Not sure this is the right castor?
Tell us your load, floor and environment. Our specialists will confirm the best model for your equipment, free of charge.
The highlighted row is this model. Other rows are variants in the same series (size, brake or tread options).
| Size | Model No | Material | Function | Wheel Size (mm) | Width (mm) | Capacity (kg) | Height (mm) | Diameter of Stem (mm) | Bearing |
|---|---|---|---|---|---|---|---|---|---|
| 3" | GB-3303503 | BLUE PU | SWIVEL | 75 | 32 | 100 | 109 | M12 X 35 / M12 X 25 | Ball Bearing |
| 3" | GB-3303507A | BLUE PU | SIDE BRAKE | 75 | 32 | 100 | 109 | M12 X 35 / M12 X 25 | Ball Bearing |
| 4" | GB-3303505 | BLUE PU | SWIVEL | 100 | 32 | 130 | 132 | M12 X 35 / M12 X 25 | Ball Bearing |
| 4" | GB-3303509A | BLUE PU | SIDE BRAKE | 100 | 32 | 130 | 132 | M12 X 35 / M12 X 25 | Ball Bearing |
| 5" | GB-3303506 | BLUE PU | SWIVEL | 125 | 32 | 140 | 156 | M12 X 35 / M12 X 25 | Ball Bearing |
| 5" | GB-3303510A | BLUE PU | SIDE BRAKE | 125 | 32 | 140 | 156 | M12 X 35 / M12 X 25 | Ball Bearing |
